Technical Parameters.
|
Heating temperature |
Room temperature - to 180°C |
| Control temperature accuracy |
±1°C |
|
Pressure setting and detection range |
0-10MPa 10MPa sensor 1pc |
| Pressure control accuracy |
±0.5% at ≥1MPa |
|
maximum time |
0.0-999h59min59s |
| timing accuracy |
±1s |
|
Test set stroke rate |
[(1000±100) stroke/h] (0.28±0.03) stroke/s |
| Control Rate Accuracy |
±1% |
|
Count range |
0-4×103 times |
| counting accuracy |
± 1 time |
|
Drive travel range |
0.00 to 50.00mm (settable) |
| Displacement detection accuracy |
±0.2mm |
|
Volume measurement range |
0.0ml～1500 ml |
| Measurement accuracy |
±1 ml |
