SGM-02 Conveyor Belt Roller Friction Tester

Overview:

SGM-02 Conveyor Belt Roller Friction Tester is in accordance with GB/T7986-1997 Conveyor Belt Roller Friction Test Method.SGM-02 Conveyor Belt Roller Friction Tester is suitable for the roller friction test of the textile-core flame-retardant conveyor belts and other flame-retardant conveyor belt roller friction test. This tester is a test device with electric force, constant tensioning force of weights and fully closed smoke hood. To change the previous lever tensioning device in the test process, with the friction tape elongation tensioning force is not constant drawbacks, as well as friction smoke caused by environmental pollution and human injury. Users should standardize the management of the equipment to ensure the reliability and continuity of the test results.

Technical parameters:

Power of the whole machine	11.2KW
power supply	AC380V 50Hz three-phase five-wire system
Roller motor power	11KW
Roller material	45# steel, nitriding treatment
Drum load speed	200±5r/min
Micro Blower	Power: 220V, 25W
air velocity	2.0±0.1m/s; air flow adjustable
	Porous tube diameter: Φ40 (inner diameter), ventilation holes inner diameter Φ: 6mm 21, spacing 13mm Distance between porous tube and roller: 600mm
weights	900kg
sizes	Mechanical cabinet 14008601900mm Electronic control cabinet 15007601700mm
Apply tensioning weights	343N weights five (one weight can automatically apply tension, 2-5 weights need to manually apply tension), automatic belt break detection
Test time recording range	99 hours, 60 minutes and 60 seconds, digital display adjustable, set time parameter value reached automatically stop.
Temperature range C	Room temperature-400°C Automatic over-temperature detection and shutdown, temperature measurement accuracy: ±1°C
	Temperature intelligent instrument display, and can print the temperature rise curve.
temperature sensor	Three, (one practical and two spare).
