SL-QZ200 Conveyor Belt Flexure Tester

Overview:

SLQZ-200 Conveyor Belt Flexing Tester is designed and manufactured according to D430-06 standard, which is a test device for determining the flexure cracking and crack growth resistance of vulcanized rubber or thermoplastic rubber after repeated flexing.

Description

Technical parameters:

slewing frequency	1-5Hz can be set and adjusted
Number of revolutions	320 times/min
ordinal number	0-999999 times, can be set arbitrarily
Longitudinal tension range	100N-445N, maximum 445N, can also be based on the specimen selection of weights, to achieve the corresponding longitudinal tensile force
Maximum power consumption	1KW
specimen size	209.5mm long x 25±2mm wide (or 450mm long x 25mm wide)
Supply Voltage	AC380V,50Hz, three-phase five-wire system (or AC220V,60Hz three-phase five-wire system)
Overall dimensions	1088(L)×750(W)×1570(H)mm
weights	300Kg
