SLO3-100 Ozone Aging Chamber

Overview.

Ozone content in the atmosphere is very small but the main factor of rubber cracking, SLO3-100 ozone aging chamber is to simulate and strengthen the atmospheric ozone environment, study the role of ozone on the rubber law, rapid identification and evaluation of rubber anti-ozone aging performance and anti-ozone agent protection effectiveness of the method, and then take effective anti-aging measures to improve the service life of rubber products. This equipment is suitable for non-metallic materials, organic materials (paint, rubber, plastic, paint, pigment, etc.) in the ozone conditions of the aging test.

Technical Parameters.

Studio Size	400×450×550mm(D×W×H)
temperature range	25℃ -65℃ Adjustable
volatility	≤±0.5°C
evenness	≤2°C
Humidity range	30-65%RH
Humidity uniformity	+2, -3% RH
heating rate	0.7～1.0℃/min
ozone concentration	50-500pphm adjustable
Ozone concentration deviation	10% National Standard
gas velocity	8～16mm/s
Rotary speed of specimen holder	0 to 50mm/s
Test gas flow rate	0-60L/min
Rotation speed of the sample frame	1 rpm (adjustable)
Fixture elongation	5 to 45%
total power	5.5KW
New specimen holder Each fixture can be installed test piece stretching to meet the type Ⅰ dumbbell piece and the actual workpiece. Dynamic and static tensile frame
