- Rotary knife motor power: 4KW
- Sanding width range: 50mm-70mm
- Sanding belt length: 2m-5m
- Spindle speed: control range 5-30r/min control accuracy ±0.5r/min
- Active wheel speed range: 5-30r/min Control accuracy ±0.5r/min
- Grinding feed speed: 1-30mm/s
- Maximum diameter of active roller: Φ200mm
- Grinding knife speed control range: 1900rpm-3000rpm control accuracy ±1r/min
- Grinding displacement detection accuracy: 05mm
- Center distance adjustment: manual and cylinder tensioning, manual locking
- Power of active wheel rotating motor: 37KW
- Sharpening knife X-axis feed motor power: 2.2KW AC servo motor
- Sharpening knife Y-axis feed motor power: 1.5KW AC servo motor
- Usage Environment.
- Temperature range: 0℃~35℃
- Humidity range: ≤90% No condensation
- Altitude: ≤2000m
SLTDJ-7.5/200/B transmission belt tooth and edge grinding machine
Transmission belt grinding machine is a kind of fly cutter fast grinding machine designed and produced for the surface hairy not polished which is basically polished by abrasive wheel at present in China, adopting the high-speed running of fly cutter to carry out the cutting edge grinding, and ensuring the consistency of the width and angle of synchronous belt and V belt, multi-wedge belt at the end of one time, in order to ensure the data of its performance, the feeding amount of fly cutter grinding and the feeding amount of transmission belt can be set up, and it adopts AC servo system for micro-variable control, and the whole machine adopts PLC and touch screen communication to make the operation more convenient and easy to understand. servo system for micro-variable control, the whole machine adopts PLC and touch screen communication for man-machine dialogue, making the operation more simple and easy to understand. The whole machine is characterized by low consumables, high productivity and low dust.
