SR-1000A Conveyor Belt Laboratory Scale Combustion Characterization Chamber

SR-1000A Conveyor Belt Laboratory Scale Combustion Characterization Chamber

Overview.

SR-1000 Laboratory Scale Combustion Characterization Chamber is suitable for scientific research units and factories to conduct laboratory scale (small scale) combustion characterization tests on fabric core conveyor belts and steel cord core conveyor belts by using propane gas torch for evaluating the reaction of conveyor belts in fire. The product conforms to GB/T3685-2009/ISO 340:2004 "Conveyor Belt Laboratory Scale Combustion Characteristics Requirements and Test Methods" specification and use requirements.

Technical Parameters.

Flame height

150-180mm

Flame adjustment temperature range

1000℃±20℃

Wind speed adjustment range

1.5m/s±0.1m/s

Torch angle

45°/90°

burners

Bunsen burner

Temperature detection display range

0-1200°C

Studio Size

660*660*1070 Unit: mm

power supply

AC220V

power frequency

50HZ

input power

28W

reagents

Propane gas (purity ≥95%)

Dimensions of the main unit

663*663*1470mm

Ingredients:

  • Test chamber
  • Lamp body rotation mechanism
  • Vapor flow regulator
